Molded PTFE Rod , 3000mm Length PTFE Rod / Rods For Chemical

Molded PTFE Rod , 3000mm Length PTFE Rod / Rods For Chemical

Quick Detail:

1.Length :100mm--3000mm or as your requirements

2.Diameters : 10mm-500mm

3.High chemical resistance

4.High temperature resistance

5.Long durability

6.Self lubricating

7. Non-contaminating

8.With high quality and competitive price

9.Any sizes available

Description:

Molded PTFE rod is manufactured by technics of extruding and molding method in the diameter

from 10 to 500mm with PTFE granular resin. As PTFE has a very low co-efficient of friction,

so the surface of molded PTFE rod has similar friction levels to ice. Molded PTFE rod can

work at -180°C ～+260°C and is the best electrical insulator of all known plastics.

Molded rod and cylinders for machining in a wide range of sizes. The most common sizes are listed

in the table below, but many other combinations of OD and ID are available. Molded rods are preferred for

machining because compression molding yields greater material homogeneity for the finished part.

Applications:

1. all kinds of chemical,

2. electrical Insulation

3. mechanical components

4. seal,Antisticking materials.


Note:All ptfe rods can be etched for bonding, and can be mounted on a plywood disk for less waste in

machining. Also can be made with filled (reinforced) PTFE to enhance the performance parameters of

PTFE. Materials available for reinforcement are Glass Fiber, Graphite, Bronze we can do.

Specifications:

Remarks:

Molded PTFE rod are available in other sizes and thickness according to customer's specific

requirements.

Competitive Advantage:

1.Excellent Chemical property

2.Virgin and recycled materials available

3.Any sizes available

4.Fast Usually
